VDWALL LVP412 LED Video Wall Processor Features:
1. 10+ Bit Faroudja® DCDI Cinema Processing
2. New Faroudja® Real Color®
3. Advanced 4×4 Pixels Interpolation Scaling Algorithm
4. AIAO( Any In Any Out ) function allows for displaying any capturing picture in specific area on the screen
5. Seamless Switching,Fade-in / Fade-out Switching
6. 3 display modes, and seamless switching between these modes
7. Unrestricted HD Picture-in-Picture ( PIP ) & Picture-Off-Picture( POP )
8. Independent H & V Scaling Ratios
9. HDMI 1.3a with HDCP, HD 1080p input
10. SDI / HD-SDI / 3G-SDI ( 1080p ) Input
11. Frame synchronous technology, no miss alignment or delay between two adjacent image output
12. Multi-machine in parallel, 4×4 in parallel can connect 7680 x 4320 LED screen
13. Fast 64-level output brightness adjustment
14. Easy setup and adjustment through keys on the panel
15. Press keys on frontal panel to directly select 7-channel input signal source, including:
1 x SDI / HD-SDI 1 x HDMI ( with HDCP ) 1 x DVI
1 x VGA 1 x DP ( DisplayPort ) 2 x CVBS
16. Robust 24 / 7 operation
VDWALL LVP40X Video Processor Model Recognition:
|
Model NO. |
DVI output quantity |
DVI output port quantity |
The max size for P4 screen |
The max size for P5 screen |
The max size for P6 screen |
|
LVP404 |
4 |
8 |
132 |
207 |
298 |
|
LVP408 |
8 |
16 |
264 |
414 |
596 |
|
LVP412 |
12 |
24 |
396 |
621 |
894 |
Fade-in / Fade-out
Frame synchronization
VDWALL LVP412 LED Video Wall Processor Parameter:
Inputs |
||||
|
Nums / Type |
2×Composite video 1×D/P( Display Port ) 1×VGA (RGBHV) 1×DVI 1×HDMI 1×SDI / HD-SDI |
|||
|
Video system |
PAL / NTSC |
|||
|
Composite Video Scope / Impedance |
1V (p_p) / 75Ω |
|||
|
VGA Format |
PC（VESA） |
≤1600×1200@60HZ |
||
|
VGA Scope / Impedance |
R、G、B = 0.7 V (p_p) / 75Ω |
|||
|
DVI Format |
SD / HD(EIA-861B) |
≤1920×1080@60HZ |
||
|
PC(VESA) |
≤1600×1200@60HZ |
|||
|
HDMI Format ( HDCP ) |
SD / HD(EIA-861B) |
≤1920×1080@60HZ |
||
|
PC(VESA) |
≤1600×1200@60HZ |
|||
|
DP Format |
SD / HD(EIA-861B) |
≤1920×1080@60HZ |
||
|
PC(VESA) |
≤1600×1200@60HZ |
|||
|
SDI Format |
SDI-SMPTE 259M-C |
576i @50HZ 480i @60HZ |
||
|
HD-SDI |
HDSDI-SMPTE292M SMPTE 274M/296M |
1080i 720P |
||
|
Input Connectors |
VGA：15pin D_Sub( Female ) DVI：24+1 DVI_D DP:DdisplayPort SDI / HD-SDI: BNC |
|||
Outputs |
||||
|
Nums / Type |
1×VGA( RGBHV ) LVP412:24×DVI ; LVP408:16×DVI ; LVP404:8×DVI 1×SDI / HD-SDI |
|||
|
DVI Format |
1024×768@60Hz |
|||
| RGB Scope / Impedance | R、G、B=0.7V(p_p) / 75Ω | |||
|
Output Connectors |
DVI ：24+1 DVI_D RGBHV : 15pin D_sub( female ) |
|||
Others |
||||
|
Control |
Panel Button / Knob |
|||
|
Power |
100-240VAC 60W 50 / 60Hz |
|||
|
Operating Temp |
5-40 ℃ |
|||
|
Humidity |
15-85% |
|||
|
Size |
190mm(high) x 400mm(wide) x 525mm (length) |
|||
|
Weight |
6.2Kg |
|||
Application
Rental Performance, Abnormity screen display, Ultra large LED screen display, Mixed LED screen display, Stage Entertainment & Theater, High-end meetings & Exhibitions etc.
Connection Diagram：
