Megmeet MCP200WS-4.5A-B Switching Power Supply

$24.00

The power supply unit consists of input stage, PFC stage, DC/DC stage, and control circuit. Input stage includes surge protect circuit, EMC circuit, soft-start-up circuit, etc. This circuits help to meet EMC regular of EN55022 etc. DC/DC stage delivers a desired output voltage. Control circuit carries out many functions as OVP, OLP, OTP, loop control.

SKU: Megmeet MCP200WS-4.5A-B Category:

Description

Megmeet MCP200WS-4 Main components functions are described as below:

G2- input rectifier
EC8- Input Capacitor
Q1- PFC Mosfet
D9- PFC Output Diode
EC8- PFC Output Capacitor
Q2&Q3- DC/DC Mosfet
Q4&Q6- DC/DC Output Synchronic-Rectifiers
EC1- Output Capacitor
U- Isolated Opt couple for feedback control

More Pictures of Megmeet MCP400WD-4.2/3.2 Switching Power Supply

Megmeet MCP200WS-4.5A-B Switching Power Supply

Additional information

Weight 0.5 kg
